You can’t have it all … Really? Nobody told that to the Release 5C. Our top-shelf trail bike is the embodiment of new-school technology. Thanks to our Level Link suspension, the Release 5 C absolutely levels the kind of drops and rock gardens that stymie bikes with even more suspension travel. At the same time, our patent-pending design allows the Release to accelerate and climb with the kind of blazing efficiency you’d normally expect from a wispy, featherweight race rig. The Release 5C, in a nutshell, is the perfect all-rounder. The bike’s performance geometry — long in the front, short in the rear, low in the bottom bracket —lends the bike stability at high speeds without sacrificing agility when the trails get tight. What’s more, we’ve decked this machine out with a peerless parts kit that includes the absolutely bomber Fox 36 Factory Float fork and Fox Factory Float DPS rear shock, an ultra-precise SRAM GX Eagle 12-speed drivetrain, a tubeless ready wheelset with e*thirteen LG1 EN rims and Novatec hubs, and quick-stopping SRAM G2 RS hydraulic disc brakes with 180mm rotors. A KS Rage-I dropper post and Race Face cockpit components round out the stellar package.
FRAME SIZE | SM/15.5 5'4" - 5'7" | MD/17 5'7" - 5'10" | LG/19 5'10" - 6'2" | XL/21 6'2" - 6'6" |
---|---|---|---|---|
Rider Height | - | - | - | - |
Bike Stand Over Height | 739.0 mm | 740.0 mm | 743.0 mm | 749.0 mm |
Bike Seat Tube Length | 394.0 mm | 432.0 mm | 483.0 mm | 533.0 mm |
Bike Top Tube Length | 585.0 mm | 610.0 mm | 635.0 mm | 660.0 mm |
Bike Head Tube Length | 100.0 mm | 110.0 mm | 120.0 mm | 130.0 mm |
Bike Head Angle | 66.0 ° | 66.0 ° | 66.0 ° | 66.0 ° |
Bike Seat Angle | 73.0 ° | 73.0 ° | 73.0 ° | 73.0 ° |
Bike Wheel Base | 1133.0 mm | 1160.0 mm | 1186.0 mm | 1213.0 mm |
Bike Chain Stay Length | 425.0 mm | 425.0 mm | 425.0 mm | 425.0 mm |
Bike Fork Offset | 44.0 mm | 44.0 mm | 44.0 mm | 44.0 mm |
Bike Bb Height | 341.0 mm | 341.0 mm | 341.0 mm | 341.0 mm |
Bike Bb Drop | 14.0 mm | 14.0 mm | 14.0 mm | 14.0 mm |
Bike Stem Length | 40.0 mm | 40.0 mm | 40.0 mm | 40.0 mm |
Bike Handlebar Width | 780.0 mm | 780.0 mm | 780.0 mm | 780.0 mm |
Bike Crank Length | 170.0 mm | 175.0 mm | 175.0 mm | 175.0 mm |
Bike Seat Post Length | 435.0 mm | 485.0 mm | 485.0 mm | 350.0 mm |
Bike Stack | 584.0 mm | 597.0 mm | 603.0 mm | 612.0 mm |
Bike Reach | 406.0 mm | 429.0 mm | 451.0 mm | 473.0 mm |
Bike Fork Travel | 150.0 mm | 150.0 mm | 150.0 mm | 150.0 mm |
