RELEASE 29 2 Metallic Black Gloss
$3 675.00
Sold out
size
Please choose
Sold out
Product Details
Brand: DIAMONDBACK BIKES
The Release 29 2 is the lankier sibling of the Release and Catch full-suspension mountain bikes. Designed for high-mileage days with a high shred factor, this aluminum trail ripper is built on a 130mm travel Level Link suspension platform. We’ve adjusted the geometry for 29-inch tubeless ready wheels while keeping the same playful attitude that our Level Link bikes have become known for. The Fox Float DPS Performance shock is outfitted with an EVOL LV air sleeve for excellent responsiveness and a bottomless feel to soak up the worst on steep, technical terrain. A 140mm travel Fox Rhythm 34 fork, Sram NX Eagle drivetrain, and hydraulic stoppers let you stay focused, no matter what the trail dishes out.
- FRAMERelease 29, 130mm Travel, Level Link Suspension Platform, Hydroformed Tubing, ISCG-05 Tabs, Boost 148x12mm Maxle Drop Out, 1.5" Tapered Headtube
- REAR SHOCKFox Float DPS EVOL LV, Performance, 3 Position Lever, 200x57mm, 22.2mm Eyelet Width
- FORKFox Rhythm 34 29", 140mm Travel, Grip Dampener w/Sweep Adjust, 1.5" Tapered Steerer, 110x15mm Thru-axle
- HEADSETFSA No. 57 Sealed Cartridge
- CRANKSSRAM Stylo 6K, 32T
- BOTTOM BRACKETSRAM DUB
- FRONT DERAILLEURN/A
- REAR DERAILLEURSRAM GX Eagle, 12 Speed
- SHIFTERSRAM NX Eagle, 12 Speed
- COGSETSRAM SX, 11-50T
- CHAINSRAM NX Eagle PG1210
- FRONT HUB32h Aluminum Boost 110x15mm Thru-axle, Sealed Cartridge Bearing
- REAR HUB32h Aluminum Boost 148x12mm Thru-axle, 5 Sealed Cartridge Bearing, Cassette
- SPOKES14g Stainless Steel
- RIMSDiamondback Blanchard 28R, Taped for Tubeless, 32h
- TIRESMaxxis Minion DHF 29x2.3" EXO, TR (Tubeless Ready), Folding / Maxxis Minion DHR II 29x2.3" EXO, TR (Tubeless Ready), Folding
- BRAKE LEVERSSRAM Guide T
- PEDALSDB CNC Platform, Sealed Cartidge Bearing w/Replaceable Pins
- HANDLEBARDB35 Aluminum 780mm Wide, 15mm Rise, 35mm Bar Bore
- GRIPSErgon GE10 Evo Lock-On
- STEMDB35 Aluminum 35mm Reach, 35mm Bar Bore
- SEATWTB Volt Comp
- SEATPOSTKind Shock Rage-I, Internal Dropper, 31.6 w/Westy 1x Remote
- EXTRASTool Kit, DB Shock Pump, Tubeless Valves, DB Mud Guard, Spare RD Hanger, Carbon Paste
- BRAKESSRAM Guide T, 180mm Front / 180mm Rear
-
FRAME SIZE SM/15.5 5'4"-5'7" MD/17 5'7"-5'10" LG/19 5'10"-6'2" XL/21 6'2"-6'6" Rider Height - - - - Bike Stand Over Height 775.0 mm 784.0 mm 791.0 mm 804.0 mm Bike Seat Tube Length 394.0 mm 432.0 mm 483.0 mm 533.0 mm Bike Top Tube Length 585.0 mm 610.0 mm 635.0 mm 660.0 mm Bike Head Tube Length 100.0 mm 100.0 mm 110.0 mm 120.0 mm Bike Head Angle 67.7 ° 67.7 ° 67.7 ° 67.7 ° Bike Seat Angle 73.0 ° 73.0 ° 73.0 ° 73.0 ° Bike Wheel Base 1134.0 mm 1159.0 mm 1185.0 mm 1211.0 mm Bike Chain Stay Length 446.0 mm 446.0 mm 446.0 mm 446.0 mm Bike Bb Height 348.0 mm 348.0 mm 348.0 mm 348.0 mm Bike Bb Drop 25.0 mm 25.0 mm 25.0 mm 25.0 mm Bike Stem Length 40.0 mm 40.0 mm 40.0 mm 40.0 mm Bike Handlebar Width 780.0 mm 780.0 mm 780.0 mm 780.0 mm Bike Crank Length 170.0 mm 175.0 mm 175.0 mm 175.0 mm Bike Seat Post Length 435.0 mm 435.0 mm 485.0 mm 485.0 mm Bike Stack 599.0 mm 599.0 mm 608.0 mm 617.0 mm Bike Reach 402.0 mm 427.0 mm 449.0 mm 472.0 mm Bike Fork Travel 140.0 mm 140.0 mm 140.0 mm 140.0 mm
